Why frame inspection ROI without a price?
Payback is a ratio of your recurring loss to a one-time cost, and the loss side is where the money actually is. Most of an inspection business case is built from numbers you already own: how many parts you make, how many defects escape, what each escape costs downstream, how many good parts you scrap, and how many hours go into manual checking. Those inputs decide the answer far more than the device price does.
Framing ROI this way also matches how inspection is quoted. A vision unit is scoped to your part, cycle time, optics and enclosure, so a headline price on a web page would be fiction. It is more useful to build the payback model with your own figures first, then request a scoped quote and drop the real number into the one cell the model leaves blank. Adente Vision is an edge-AI visual inspection unit built by ADENTE Advanced Engineering Technologies, part of the Aden Group, sold through automation system integrators, and it is priced through that integrator against your scoped line, not from a list.
The rest of this post is the worksheet: the inputs, where to source each one, and how they turn into a payback figure you can defend.
What inputs does an inspection payback model need?
An inspection payback model needs six inputs, and every one of them lives in a system you already run. You do not need a vendor to supply them; you need to pull them from your own MES, quality log and timesheets.
The six inputs are production volume, current escape rate, cost per escaped defect, current false-reject and scrap rate, manual inspection labor, and time-to-value. The table below names where each one comes from and how it enters the model, so you can fill it in before you talk to anyone. Keep the units consistent (per shift or per year) across all six.
| ROI input | Where to source it | How it feeds payback |
|---|---|---|
| Production volume (parts/shift or year) | MES, line counter, PLC part count | Scales every other figure into an annual number |
| Current escape rate (PPM to customer) | Customer scorecard, returns and warranty log | Sets how many escapes better inspection recovers |
| Cost per escaped defect | Rule-of-ten model, warranty, recall and rework records | Values each recovered escape |
| False-reject / scrap rate | Quality log, scrap-bin weight, rework hours | Sets yield recovered by higher precision |
| Manual inspection labor | Timesheets, sampling plan, inspector headcount | Labor shifted from sampling to exception handling |
| Install and training time | Vendor answer (about 30 min install, training under 48 h) | Time-to-value and any line downtime to deploy |
How do you value recovered escapes at a low false-negative rate?
Recovered escapes are usually the largest line in the model, and they are simple to size once you know your escape rate and the cost of one escape. Multiply the escapes you expect to catch by the cost each one carries downstream, and that annual figure is what better inspection is worth on the escape side alone.
The catch is honesty about the false-negative rate. No inspector catches everything, so model the improvement, not perfection. On a live cap-inspection line, Adente Vision ran a 0.69% false-negative rate, which is a reference for what a low escape rate looks like; your own number depends on your parts and defect and needs an application-specific measurement. Use a conservative recovered-escape fraction, and let the downstream cost per escape carry the weight. That downstream cost is where the rule-of-ten applies: quality literature has long held that the cost to find and fix a defect multiplies at roughly ten times per stage it travels, from in-station to final assembly to the field, so an escape caught in-station is far cheaper than the same defect returned by a customer.
How does labor shift from sampling to exception handling?
Manual inspection labor rarely disappears; it moves. When a unit checks every part on the line, the operator stops sampling and starts handling exceptions: reviewing the parts the system flags, confirming borderline calls and feeding back edge cases. That is a real change in headcount allocation, and it belongs in the model as a shift, not a deletion.
Size it from your current sampling plan. If a shift spends a fixed number of hours on manual visual checks today, estimate how many of those hours become exception review once 100% inspection is running, and value the difference at your loaded labor rate. Add the accuracy gain that comes from removing inspector fatigue on a repetitive check, which is hard to price but shows up in your escape and false-reject numbers over time. The unit inspects on-device at about 30 ms per part against a catalog bound of 0.5 s per part and 100+ parts per minute, so the check keeps up with the line rather than becoming the new bottleneck.
How do you turn the framework into a scoped quote?
The framework gives you everything except the device price, and that is the one number you get by scoping. Once your six inputs produce an annual benefit, you know the maximum price at which the investment still pays back inside your target period, which is exactly the figure to take into a quoting conversation.
From there, request a scoped quote against your real part, cycle time and enclosure need, drop it into the blank cell, and read the payback. Because the unit trains on about 20 good images with model training under 48 hours and installs in about 30 minutes by one person, the deployment cost and downtime that eat into payback are small and knowable rather than open-ended. For how F1 and the false-negative rate underpin the recovered-escape maths, see the false-negative rate as an inspection metric; for the range of checks this covers across sectors, see the applications overview; and for the full method behind few-shot inspection, see the pillar guide on AI visual inspection.
