Which fieldbus should an inspection cell use?
The rule is short: the inspection cell should speak whatever the line controller already speaks. On a Siemens PLC that is usually PROFINET, on a Rockwell or Allen-Bradley PLC it is usually EtherNet/IP, and Modbus TCP is the vendor-neutral common denominator almost every controller reads. Choosing the bus is less about which protocol wins in the abstract and more about which one your PLC is already wired for.
The reason this matters is commissioning time. An inspection unit that spoke only one protocol would force a gateway or protocol converter into the cell, one more device to configure, power and troubleshoot. When the unit speaks the same bus as the controller, the pass/fail result lands in a tag or register the PLC already polls, and bring-up is a mapping exercise rather than an integration project. Adente Vision is an edge-AI visual inspection unit built by ADENTE Advanced Engineering Technologies, part of the Aden Group, sold through automation system integrators. It exposes five industrial protocols so the integrator matches the bus to the line, not the line to the unit.
What is each protocol best at?
Each common inspection-cell bus has a home defined mostly by the controller in the cabinet. PROFINET is the default on Siemens automation and dominates many European lines; EtherNet/IP, governed by ODVA, is the default on Rockwell and Allen-Bradley controllers and common across North America; Modbus TCP is the simple, openly documented option that runs on almost anything with an Ethernet port. Treat the controller brand as the first filter and the choice usually follows.
Two more protocols cover the edges of the range. Where tightly synchronised motion makes cycle determinism the constraint, EtherCAT is the specialist bus that keeps the result aligned to the motion cycle. Where the result needs to travel to MES or SCADA as structured, self-describing data rather than a single bit, OPC UA is the carrier. The unit supports all five, so the same hardware drops into a Siemens cell, a Rockwell cell, or a mixed brownfield line without a change of part.
Will the fieldbus slow the inspection down?
On a well-designed cell the bus is not the bottleneck. The measured inference field result is about 30 ms per part, and the catalog bound is 0.5 s per part at throughput of 100+ parts per minute, while an industrial fieldbus cycle is typically far shorter than the inspection decision itself. The protocol choice rarely changes your cycle-time budget, so pick for controller fit and diagnostics, not for raw speed.
What the fieldbus actually decides is determinism and visibility. It sets how tightly the result aligns to the motion cycle and how much status the controller can see, not how fast the model runs. The number you can commit to for a specific cell still needs an application-specific measurement on your parts and lighting, because inference time depends on the model and the image, not the bus. For most pass/fail checks, any of the five protocols carries the result well inside the cycle.
How do the protocols compare for an inspection cell?
Read the table by starting with the controller you already run, then confirm the result type the cell has to carry. The first three rows cover the great majority of cells; the last two are for determinism-critical motion and for structured reporting to a plant system.
| Protocol | Typical controller / context | Best for in an inspection cell |
|---|---|---|
| PROFINET | Siemens automation, common in Europe | Pass/fail and coded results on a Siemens line |
| EtherNet/IP | Rockwell / Allen-Bradley, common in North America | Pass/fail and coded results on a Rockwell line |
| Modbus TCP | Vendor-neutral, almost any Ethernet controller | Lowest-friction path on mixed or brownfield lines |
| EtherCAT | Deterministic, tightly synchronised motion cells | Cycle-locked capture where timing is tight |
| OPC UA | MES / SCADA reporting layer | Structured per-part data, not a single bit |
When is plain 24V I/O the better choice?
Sometimes the right answer is no fieldbus at all. If the result the cell hands over is a simple pass/fail, four discrete 24V outputs are more reliable and faster to commission than any bus: no tag mapping, no configuration file, just a wire that goes high on a fail. The unit provides 4 inputs and 4 outputs at 24V for exactly this case, and the same I/O triggers the capture from an encoder pulse, a photoelectric sensor or a fixed interval.
Reach for a fieldbus the moment the result is more than one bit: a variant code to steer a robot program, a confidence value, a part count, or richer diagnostics the controller wants to log. You can bit-code a few classes across spare outputs, but that runs out quickly, which is where PROFINET, EtherNet/IP, Modbus TCP, EtherCAT or OPC UA take over. The wiring you ran for pass/fail stays useful for the reject and interlocks, so adding a bus later does not mean re-mounting the unit. For the pass/fail handshake in detail, see the sibling post on sending results over 24V discrete I/O.
